Processor
Up to one Intel® Xeon® E-2200 product family processor with up to 8 cores per processor
Operating System
Canonical® Ubuntu® Server LTS
Citrix® Hypervisor
Microsoft® Windows Server® LTSC with Hyper-V (2016 and 2019)
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
Memory
DIMM Speed
Up to 2666MT/s
Memory Type
UDIMMs
Memory Module Slots
4 DDR4 DIMM slots
Supports registered ECC DDR4 DIMMs only
Maximum RAM
UDIMM 64GB
Storage
Front Bays
Up to 4 x 3.5 hot-plug SAS/ SATA/SSD
Up to 4 x 3.5 cabled SAS/ SATA/SSD
Up to 2 x 3.5 cabled SAS/SATA/ SSD
Max 56TB for 4 HDD configuration
Storage Controllers
Internal Controllers
PERC H330, H730p, HBA330
External Controllers
12 Gbps SAS HBA
Software RAID
S140
Internal Boot
Boot Optimized Storage Subsystem (BOSS):
2 x M.2 240GB (RAID 1 or No RAID)
1 x M.2 240GB (No RAID only)
Internal Dual SD Module (IDSDM):
2x microSD (16GB, 32GB or 64GB)
1x microSD (16GB, 32GB or 64GB)
Security
Cryptographically signed firmware
Silicon Root of Trust
Secure Boot
System Lockdown (requires OpenManage Enterprise)
Secure Erase
TPM 1.2/2.0, TCM 2.0 optional
Management
Embedded / At-the-Server
iDRAC9
iDRAC RESTful API with Redfish
iDRAC Direct
Consoles
OpenManage Enterprise
OpenManage Power Center
Mobility
OpenManage Mobile
Tools
Dell EMC RACADM CLI
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
iDRAC Service Module
IPMI Tool
OpenManage Server Administrator
OpenManage Storage Services
OpenManage Integrations
BMC Truesight
Microsoft® System Center
RedHat® Ansible® Modules
VMware® vCenter
OpenManage Connections
IBM Tivoli® Netcool/OMNIbus
IBM Tivoli® Network Manager IP Edition
Micro Focus® Operations Manager I
Nagios® Core
Nagios® XI
Power Supplies
250W Bronze
450W Platinum
Ports
Network Options
2 x 1GbE LOM
Front Ports
1 x Dedicated iDRAC direct micro-USB
1 x USB 2.0
Rear Ports
1 x Serial
2 x USB 3.0
1 x VGA
Internal Ports
1 x USB 3.0
Slots
PCle
2 x PCIe Gen3 slots
Bezel
Optional security bezel
Form Factor
1U Rack Server
Dimensions & Weight
Height
42.8mm (17.1")
Width
434.0mm (17.1")
Depth
595.6mm (23.5") (3.5” HHD config)
Weight
12.2kg (29.9lbs.)
Dimensions do not include bezel
Rack Support
ReadyRails™ sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks).
